/ F2 Pro Pellet
pellet extruder and all the advantages of the F2 Pro printer
- FULL CONTROL
- HYBRID PRODUCTION
- FULL CONTROL
- HYBRID PRODUCTION
/ F2 Pro Pellet
pellet extruder and all the advantages of the F2 Pro printer
F2 Pro Pellet combines the benefits of the Pro printer
with fast pellet extrusion technology
with fast pellet extrusion technology
The F2 Pro Pellet is an industrial 3D pellet printer ideal for fast 3D printing. The technology of three-zone heating of pellets inside the extruder ensures uniform material supply and high quality of the resulting product.
In addition to standard granules for printing (ABS, PLA, PP, PE, etc.), the printer allows you to print with secondary raw materials: recycled plastic granules PET, PP, ABS, HDPE, LDPE, etc.
In addition to standard granules for printing (ABS, PLA, PP, PE, etc.), the printer allows you to print with secondary raw materials: recycled plastic granules PET, PP, ABS, HDPE, LDPE, etc.
Granules are much cheaper than classic filament, and the resulting products are perfectly subject to post-processing - turning, milling, etc., which makes it possible to introduce additive technologies into the production chain of any manufacture.
The technology is suitable for creating disposable molds, punches, dies for laying out composites, prototyping, creating models, etc.
The technology is suitable for creating disposable molds, punches, dies for laying out composites, prototyping, creating models, etc.
High-end
mechatronics
mechatronics
precision guides and ball screws ensure high accuracy of movement and repeatability
Chamber
chamber heated to 100°C with convection
Priting area
1000*600*1000 mm
Printing bed
quick-change printing platform heated to 140°С (optionally up to 160°С)
User Interface
original electronics
and intuitive interface
and intuitive interface
Pellet extruder
heated to 400°C, it can quickly create large items
(throughput up to 3 kg per hour)
(throughput up to 3 kg per hour)
High-end
mechatronics
mechatronics
precision guides and ball screws ensure high accuracy of movement and repeatability
Chamber
chamber heated to 100°C with convection
Priting area
1000*600*1000 mm
Printing bed
quick-change printing platform heated to 140°С (optionally up to 160°С)
User Interface
original electronics
and intuitive interface
and intuitive interface
Pellet extruder
heated to 400°C, it can quickly create large items
(throughput up to 3 kg per hour)
(throughput up to 3 kg per hour)
User Interface
Original electronics and intuitive interface
Minimal training is required; by looking at the interface, you will immediately understand how to operate the printer.
User Interface
Original electronics and intuitive interface
Minimal training is required; by looking at the interface, you will immediately understand how to operate the printer.
printing chamber
Heated chamber with forced convection
Forced convection of the chamber and uniform heating allows printing large-sized parts with high interlayer adhesion.
Parts of any size do not delaminate or deform.
Parts of any size do not delaminate or deform.
printing chamber
Heated chamber with forced convection
Forced convection of the chamber and uniform heating allows printing large-sized parts with high interlayer adhesion.
Parts of any size do not delaminate or deform.
Parts of any size do not delaminate or deform.
extruder
Pellet extruder
The technology of three-zone heating of pellets inside the extruder ensures uniform material feed and high quality
of the printed item.
of the printed item.
extruder
Pellet extruder
The technology of three-zone heating of pellets inside the extruder ensures uniform material feed and high quality
of the printed item.
of the printed item.
Built-in air filters
Built-in air filtration system traps all particles
When heated, some plastics can evaporate harmful substances, for example, vapors of styrene derivatives, hydrocyanic acid, acetaldehyde.
Built-in high-temperature filters block not only harmful particles, but also unpleasant odours.
Built-in high-temperature filters block not only harmful particles, but also unpleasant odours.
Built-in air filters
Built-in air filtration system traps all particles
When heated, some plastics can evaporate harmful substances, for example, vapors of styrene derivatives, hydrocyanic acid, acetaldehyde.
Built-in high-temperature filters block not only harmful particles, but also unpleasant odours.
Built-in high-temperature filters block not only harmful particles, but also unpleasant odours.
printing bed
Quick-change print platform
heated to 140°C
heated to 140°C
The quick-change printing bed makes the printing process fast and easy.
This avoids damage to models with large dimensions, and also allows you to use the printer almost without interruptions between printing processes.
This avoids damage to models with large dimensions, and also allows you to use the printer almost without interruptions between printing processes.
printing bed
Quick-change print platform
heated to 140°C
heated to 140°C
The quick-change printing bed makes the printing process fast and easy.
This avoids damage to models with large dimensions, and also allows you to use the printer almost without interruptions between printing processes.
This avoids damage to models with large dimensions, and also allows you to use the printer almost without interruptions between printing processes.
